IR High Speed Dome
- Brand SELTI
- Type SKS-IR8636H10
IR function
● Integrated Infrared Lens design can reduce the infrared reflection, andimprove 10%
infrared effect.
● All-Metal Aluminum structure design for quickly cooling. IR LED boardconnect to the metal
cover, spread the heat form metal cover.
● IR LED ring layout,the circular optic filed fill the light more uniform.
● IR LED Board use high thermal conductivity of aluminum plate(ThermalConductive >2.0/M.k) .
Conduct heat faster to extend the service life of LED.
● IDS ( Intelligent Light dimmer System), kinds of infrared mode can be configed.
● Independent MCU IR control system,can set a variety of IR mode.Remote upgrade system.
● The output power of IR LED and start illuminance 10 level can be adjusted.
● IR control and optical filter can be switched synchronizational.
System
● 1/2.8”Sony Progressive Exmor Sensor 1000TVL 36X Optical Zoom
● IR distance：120m 12PCS infrared lights
● CGS(cooling gas system), cooling rapidly
● IP66,TVS4000V lightning protection and voltage transient protection.
● Multi-channel temperature control system, detect temperature of system, camera and IR LED
board in real time.
● Built-in sensitive and stable motor
● Support RS-485 update
● Support intelligent 3D positioning with special protocol
● Dip switcher built on side of speed dome, easily operation
● GUI (graphical User Interface) OSD Menu.
● Support Timing Action,Pattern scan,Preset scan,horizontal scan,etc.
● Password protection function.
Application scenarios
Our products can be widely used in a wide range of high-speed matt or a feeble light space.For example : River,Forest,Road,Railway,Airport,
port,Park,street,Station,Large Venues,Outside of the residential area ,etc.
|
Model |
SKS-IR8636H10 | |
|
Function |
IR distance: |
100-120 m |
|
Pan Range |
360°endless |
|
|
Pan Speed |
6°-40°/s |
|
|
Tilt Range |
0°- -90° (Auto Flip) |
|
|
Tilt Speed |
5°-17°/s |
|
|
Manual Speed |
High, medium, low (adjustable) |
|
|
Proportional Zoom |
Support |
|
|
Number of Preset |
128 |
|
|
Patrol |
4 |
|
|
Pattern |
1 |
|
|
Scan between two presets |
Support |
|
|
Park Action |
presets/pattern/patrol/scan between two presets/ auto |
|
|
Zone Scanning/Display |
Support |
|
|
PTZ Position Display |
On/Off |
|
|
Alarm(optional function) |
2 inputs, 1 outputs |
|
|
Camera |
Horizontal resolution |
1000TVL |
|
Video system |
PAN/NTSC |
|
|
sensor |
1/2.8 inch, SONY Progressive Exmor Sensor |
|
|
Effective pixels |
PAL:1280(H)×720(V) |
|
|
illumination |
0.001Lux/IR ON 0lux |
|
|
Video output |
1Vp-p Composite Output(75Ω/BNC) |
|
|
S/N |
≥48Db |
|
|
Optical zoom |
36X |
|
|
Focus |
Auto/manual |
|
|
Image effects |
Auto/color/black/Negative |
|
|
Back-light compensation |
On/off |
|
|
White balance |
On/off/indoor/outdoor |
|
|
Input/Output |
Monitor Output |
1Vp-p Composite Output(75Ω/BNC) |
|
Other |
Menu |
English |
|
RS485 Protocols |
PELCO-D, PELCO-P, , self-adaptive |
|
|
Bare camera Automatic Diagnosis |
Support Sony, Hitachi, LG, CNB, Canon,. |
|
|
Power Supply |
DC 12V/4A ( AC 24V optional) |
|
|
Power Consumption |
40W MAX (heater) |
|
|
Working Temperature/Humidity |
-20°C-60°C, ≤90%RH( frostless ) |
|
|
Protection Grade |
TVS4000V lightning protection, surgeprotection and voltage transient protection, weather proof: IP66 |
|
|
Package size (mm) |
300x300x450mm |
|
|
Weight (Kg) |
6.5 |
|
Note: The picture is for reference only. Please take actual product as standard
