4CH 1080P AVR
- Brand SELTI
- Type ST-AVR8004H
AHD DVR（AHD，NVR，DVR 3 in 1)
>>Pure Analog：4*AHD-H，4*AHD-M ;
>>Mixed：2*AHD-H（analog）+2*1080P（network）; 4*AHD-M（analog）+4*720P（network）;
>>Pure Network：4*1080P，1*1080P+8*720P，20*960H;
Support AHD-H series front-end non-real-time encoding;
Support VGA, HDMI HD output;
Support Cloud technology, easy to achieve a variety of network penetration, one step to remote monitoring
getting rid of various complicated network settings, easy and simple to operate;
Support various mobile monitoring:（IOS, Android）.
Support multiple web browsers（IE,Chrome,Firefox,Safari）;
Support more than 20 languages, no nation boundaries;
perfect protection circuit, unique triple watchdog function
Supporting web, CMS, center platform management software MYEYE
|
|
Model |
ST-AVR8004H |
|
System |
Main processor |
Hi3531 |
|
Operating system |
embedded Linux |
|
|
System resources |
Simultaneously multi-channel real-time recording, playback, network operation, USB backup |
|
|
Interface |
Operator interface |
support 16-bit true color graphical menu interface and mouse operation |
|
Preview |
1/4 |
|
|
Codec |
H.264(High Profile) |
|
|
Monitor quality |
VGA,HDMI：HD |
|
|
Playback quality |
AHD-H/ AHD-M /D1 |
|
|
Encode ability |
4*AHD-M@25fps/4* AHD-H@25fps |
|
|
Decode ability |
4*AHD-M@25fps/8* AHD-H@25fps |
|
|
Video |
Multi-mode input |
analog: 4* AHD-H；4* AHD-M； hybrid: 2*AHD-H（ananlog）+2*1080P（network） 4*AHD-M（analog）+4*720P（network） Network only：1*1080P+8*720P；4*1080P；20*960H； |
|
|
Motion Detection |
Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel) |
|
Audio |
Audio compression |
G.711A |
|
Intercom |
support |
|
|
Record &playback |
Record mode |
manual>alarm>motion detection>timing |
|
Local Playback |
4ch(local input mode) |
|
|
Search mode |
Search by time, calendar, event, channel |
|
|
Storage& backup |
Space occupation |
1080P 20~30G/day*channel;720P ~20G/ day*channel ;960H 12~20G/ day*channel; audio：691.2M/ day*channel |
|
Video storage |
HDD, network |
|
|
A / V PORT |
Backup mode |
Network, USB hard disk, USB burner, SATA burner |
|
Video input |
4ch BNC |
|
|
Video output |
1ch VGA, 1ch HDMI |
|
|
Loop Vout |
N/A |
|
|
Audio input |
4ch RCA( Can be extended to 8ch) |
|
|
Audio output |
1ch RCA |
|
|
External |
Alarm input |
0( Can be extended to 4ch) |
|
Interface |
Alarm output |
0( Can be extended to 1ch) |
|
Network interface |
RJ45 10M/100M |
|
|
PTZ control |
1*RS485, Support kinds of PTZ protocols |
|
|
USB |
2* USB 2.0 ports |
|
|
HDD |
1*SATA ports (Max 4TB/per) |
|
|
Wireless |
3G, WIFI (extend via USB) |
|
|
Power supply |
12V/4A |
|
|
General |
Power Consumption |
<15W (without HDD) |
|
Temperature |
0℃-＋55℃ |
|
|
Humidity |
10%－90% |
|
|
Working environment |
86kpa—106kpa |
|
|
Dimension |
335mm*250mm*50mm |
|
|
Weight |
220g |
Note: The picture is for reference only. Please take actual product as standard
