Network decoding keyboard

2015-7-25      View:
  • Brand   SELTI
  • Type   ST-NKB-3009
  • Inquire Now
Introduction



Using the Linux operating system, stable and reliable.

Can manage network video decoding matrix.
Equipped with three-dimensional joystick, full Chinese Chinese display operations.
Support different brands with different resolution webcam hybrid decoding.
There are 1 HDMI and 1 VGA output (homologous output).
Automatically search the IP address of the network camera, access can be up to more than 60000

 the number of the IPC (see project requirements optional).
Automatically detect IP address conflicts, save time and worry.
Network camera access across network segments, compatible with ONVIF network protocolPanasonic,

 Samsung, Sony, Hikvision, Dahua, Yaan, Honeywell, Bosch, the world Albert, parti, Ming Jing, Jing Yang,

Vikons, Sunny International, Putian vision, Lang Chi, the Yellow River, British Fractalist , Jie Gao,

Shi Jizhong Wei, waveparticle, Kyoho, Jin Sanliother network cameras andDays Vision Network HD module (UC),

SELTI Network HD module (CMS), nine security network HD module And with ONVIF network protocol

dome cameras and other manufacturers.

Support USB mouse to operate the system.
Automatic switching keyboard bindings camera ID number, you can change the keyboard corresponding

  IP needed to switch ID.
Built-in database, set the parameters for the user are stored in the database.
Built-in virtual computer keyboard function, use the mouse cursor to edit letters or characters.
OSD function, network cameras can edit the information or the name of the geographical.
Each split screen can switch to any network camera signal display.
ONVIF-compliant network can be controlled HD ball machine.
You can switch the screen grouping, multi-screen automatic round robin, single-screen automatic  polling.



Product Type

ST-NKB3009

    Keyboard

   parameters

Lever

three-dimensional

Button

Use Germany mechanical key switches

Keycaps

Original raw material made of plastic, durable without deformation, laser engraving word indelible

Video Output

HDMI  Output Interface

1 PCS

VGA  Output Interface

1 PCS

Split screen number

149

Output resolution

1920*1080@60/50HZ,1280*720@60/50HZ

Decoding parameters

Access network cameras and network HD ball number of machines

A total of 256 PCS, beyond the need to increase the number of

Decoding channel

9

At the same time decoding display screen

1 way 1080P or 4 way 720P or 9 way D1

Control Interface

Network Interface

RJ45 Fast Ethernet port

USB Interface

yes

Other

Powered by

9V/1A or 12V/1A Available

Size

LWHmm

352*190*52/32After high 52Before high 32

Weight

With packaging 2.5KG


 Note: The picture is for reference only. Please take actual product as standard
