● Max 36ch IP cameras connection
● Up to 36ch HD realtime transmission
● Up to 36ch @5M / 3M / 1080p / 1.3M / 720P / D1 realtime recording
● Up to 2-screen output: 2 HDMI or 1HDMI + 1 VGA
● Support 16 hot-swap SATA HDDs (max. 4TB for each) to better its scalability and flexibility
● Support Multi-brand network cameras: Hikvision, Dahua, XiongMai, Topsee, NIHON, ONVIF etc. IP cameras
● ONVIF Version 2.3 conformance

● Max. 16 channel 5M / 3M / 1080P simultaneously playback,Smart Search,Icon Search

● Browser supported multi platform (IE / Firefox / Chrome / Safiri)Android based NDVR Client for smart phone / pad
  iOS based NDVR Client for smart phone / pad

● Face Detection;Intrution Detection;Object Counting;Movement Direction Detection;Missing Object Detection,

  Unattended Object Detection, Tripwire Detection

● Max. 32 POS connection in one system,Support LAN connection and COM port connection,Max. 4 channel video playback

  with POS information
● Support POS devices which send plain text data based on ASCII code





NVSS Specification
Model	SNVS-P8636H16
Main Processor	Embedded Intel i5
RAM	4GB
Operating System	Embedded LINUX
System Resources	live, recording, playback, backup & remote access
Control Mode	Mouse
IP Camera Input	36ch@5M / 3M / 1080P / 720P / D1
IP Camera Supported List	Hikvision, Dahua, Nihon, ONVIF, including IP camera / DVR / NVR /HCVR / HDTVR
Video Output	2 HDMI, or 1ch VGA + 1ch HDMI sync video output
Voice Intercom	1ch audio & 1ch Mic in, 1ch audio out
Display Split	All screens: 1/4/6/9/13/16/20/25/33/36/40/49/64
Resolution	Self adapted, supports 1920*1080 / 1600*1050 / 1280*1024 / 1024*768
Tour Display	16 Display groups with sequence supported
OSD	Camera title, time, date, video loss, recording
Compression	H.264
Recording Resolution	5M, 3M, 1080P, 720P, 960H, D1, CIF, QCIF, VGA
Max Encoding Speed	36ch 1080P @ 25/30fps
Recording Bit Rate	Max 256Mbps
Recording Quality	--
Recording Mode	Manual, Schedule(Continuous, Motion detection, Sensor, Normal & Motion, Normal & Sensor, Stop
Recording Priority	Manual >Alarm >MD >Regular
Trigger Events	Recording, PTZ movement, Alarm, Email, Buzzer
Motion Detection	Support
Video Loss & Camera Blank	Support
Alarm Input	4ch, low level effective, green terminal interface
Relay Output	2ch, Relay contact(1A@24VDC), NO/NC programmable, green terminal interface
Playback Channel	9ch 5M(12fps) / 3M(20fps) / 1080P(30fps) / 16ch 720P / D1
Search Mode	Time/Date, Alarm, MD & Exact search (accurate to second), Smart search, Icon Search
Playback Function	Simultaneous play, single frame, Icon Search, Record mode filter, Backup, Grab
Backup Mode	USB HDD, network download
Ethernet	2 * independent 1000Mbps RJ45 ports
Max Remote Users	Upload max 256 channel video
Hard Disk	16 * 4TB Hot-Swap, up to 64TB totally
HDD Management	Auto search HDD and set to ready for record
USB Interface	4 USB 2.0
RS232	1
Power Supply	100V-240Vac, 47-63Hz
Power Consumption	Max. 800W(Include HDD)
Working Environment	Temperature: 0˚C~60˚C; Humidity: 10%~80% ( non-condensation)
Dimension	650mm×440mm×133mm (W×D×H)
Weight	20Kg
