8CH H.264 NVR
- Brand SELTI
- Type SNVR-S7008D2
This 2*SATA 8CH NVR SNVR-S7008D2, can apply for 3Megapixel IP Camera for Video Recording;Dual USB Port, Can connect IP camera,
IP speed dome camera; support Onvif protocol.
lSupport multiple high-definition network camera access;up to 1080P
lSupport VGA, HDMI 1080P full HD output simultaneously;
lSupport web, CMS, MYEYE platform, provide SDK development;
lSupport multiple cloud technology, network penetration, alarm information pushed to your phone and other functions;
lSupport multiple network services (support DHCP, FTP, DNS, DDNS, NTP, UPNP, EMAIL, IP searches, Alarm Center,etc.);
lSupport ONVIF & GB28181;
lSupport several mobile system (iOS, Android);
lSupport multiple web browser access (IE, Chrome, Firefox, Safari);
lSupportLanguages:English,Finnish,French,German,Greek,Italian,Japanese,Polish,Portuguese,Russian,Spanish,Thai,
Chinese,Chinese(traditional),Turkish)
lPerfect protection circuit, unique triple watchdog function;
lVisit remotely,built-in ARSP,remote monitoring by one step
|
System |
Model |
SNVR-S7008D2 |
|
Main Processor |
Hi3535 |
|
|
Operating System |
Embedded LINUX |
|
|
System Resources |
multi-channel real-time recording and playback, multi-channel net operation for several persons, USB backup |
|
|
Operation interface |
16-bit true color graphical menu interface and mouse support |
|
|
Menu display |
1/4/8 Screen |
|
|
Video |
Video Standards |
PAL (625 line,50 f/s);NTSC (525 line,60 f/s ) |
|
Video Compression |
H.264 main profile |
|
|
Surveillance quality |
Monitor:D1;VGA: HD; HDMI: HD |
|
|
Playback quality |
1080P/720P/960H/D1/HD1/CIF/ QCIF |
|
|
Video input |
8*1080P/8*960P/8*720P/ |
|
|
Motion Detection |
Support |
|
|
Audio |
Audio Conpression |
G711A |
|
Bidirectional Talk |
No |
|
|
Record &Playback |
Recording Mode |
Manual>Alarm>Video Detection>Continuous |
|
Local Playback |
1*10800P/2*10800P/4*720P Real Time Playback |
|
|
Search Mode |
Time/Date search, exact search, channel search |
|
|
Storage &Backup |
Space Occupation |
Video: CIF 4~5G/D*CH, D1 8~10G/D*CH,960H 12~20G/D*CH,720P 24~30G/D*CH; 1080P 40~60G/D*CH ,Audio: 691.2M/D*CH |
|
Recording Storage |
Local HDD / Network |
|
|
Backup Mode |
Network/U-disk / USB-HDD / USB DVD-RW / SATA-RW |
|
|
Interface |
Video Input |
RJ45 |
|
Video Output |
1 * VGA+1 * HDMI + 2*BNC |
|
|
Audio Input |
1 *RCA |
|
|
Audio Output |
1 *RCA |
|
|
Alarm Input |
8CH |
|
|
Alarm Oput |
1CH |
|
|
Net Interface |
1× RJ45, 10M / 100M ,self-adaptive Ethernet port |
|
|
PTZ Control |
1 RS485, support 19 kinds of PTZ protocols |
|
|
USB Interface |
2* USB2.0 port for mouse and backup |
|
|
Hard Disk |
2 SATA port(Max 4T) |
|
|
Wireless Interface |
3G / WiFi (extend via usb) |
|
|
Others |
ONVIF protocol |
Support |
|
Power Supply |
12V/4A |
|
|
Dimensions |
L255mm* W225mm* H45mm |
Note: The picture is for reference only. Please take actual product as standard
